Clausing Kalamazoo 13" x 18" Semi-Automatic Swivel Horizontal Saw, Model MS1318SA - NEW
Clausing Kalamazoo 13" x 18" Semi-Automatic Swivel Horizontal Saw, Model MS1318SA - NEW
Prices subject to change every 10 days due to economic changes please call us to verify the price!
SKU #0720003
13" (330mm) Semi-Automatic Miter Bandsaw
Standard Features...
- Advanced hydraulic system provides dependable power for powered clamping and raising the saw head at end of cut
- Full stroke machine vise for tight clamping of any material from operator's panel
- Operator's panel pivots allowing operator to control saw from the rear of the machine
- Swivel sawhead allows the operator to accurately pivot head for angle cuts from 0°, for a 90° cut, to 60°
- Carbide blade guides provide excellent stability for the saw blade
- Variable blade speed
- Power chip brush removes chips from the blade extending blade life
- Integrated coolant system
- Cast iron moveable guide arms provide rigidity and stability for an accurate cut
- Flushing hose
- Adjustable work stop
- Tool box with tools
- Manual & parts list
- Two (2) year limited warranty
| Drive Motor | 3 Hp (2.2kw) |
| Hydraulic Motor | .25 Hp (.19kw) |
| Hydraulic Oil Capacity | 2 gallons (7.5 liters) |
| Coolant Motor | .125 Hp (.1kw) |
| Coolant Capacity | 7.8 gallons (7.5 liters) |
| Blade Speeds (Inf. Variable) | 102-377 fpm (31-115 m/min) |
| Blade Size | 1" x .035" x 13'-7" |
| (25 x .9 x 4150mm) | |
| Swivel Angle Range | 0° to 60° |
| Cutting Capacity | |
| Round @ 90° | 13" (330mm) |
| Round @ 45° | 11.5" (292mm) |
| Round @ 60° | 8.7" (220mm) |
| Square @ 90° | 10.6" (270mm) |
| Square @ 45° | 10.5" (268mm) |
| Square @ 60° | 8.7" (221mm) |
| Rectangular @ 90° | 18.5" x 10.6" (470 x 269mm) |
| Rectangular @ 45° | 10.5" x 10.5" (268 x 268mm) |
| Rectangular @ 60° | 8.7" x 8.7" (220 x 220mm) |
| Bed Height | 33" (838mm) |
| Dimensions: | |
| Length | 75" (1905mm) |
| Width | 34" (863mm) |
| Height | 55.5" (1410mm) |
| Net Weight | 1,400 lbs (635kg) |
| Shipping Weight | 1,850 lbs (839kg) |
