Dake 50 Ton Moveable Table H-Frame Press, Model 42-304 - NEW
Dake 50 Ton Moveable Table H-Frame Press, Model 42-304 - NEW
SKU #0914027
| Number | 942304 |
| Capacity | 50 tons |
| Operation | Air |
| Horsepower | n/a |
| Voltage | n/a |
| Width between uprights | 32- 3/4" |
| Width between table channels | 7- 1/4" |
| Minimum ram to table | 10- 7/8" |
| Maximum ram to table | 40- 7/8" |
| Ram travel | 10" |
| Screw Travel | n/a |
| Horizontal workhead travel | n/a |
| Footprint | 37" x 43" |
| Height | 108" |
| Weight | 1,500 lbs |
| Base | 37" x 43" |
| Ram advance speed | 65 ipm |
| Pressing speed | 3 ipm |
| RPM | n/a |
| Air Pressure | n/a |
REF: 000389
