DoAll 33.5" x 40" Dual Column Enclosed CNC Bandsaw, Model DC-1000CNC - NEW
DoAll 33.5" x 40" Dual Column Enclosed CNC Bandsaw, Model DC-1000CNC - NEW
SKU #1120034
Machine Capacity: 33.5 x 40" (850 x 1000mm) | Round (Tube or Solid): 33.5" (850mm)
Production Level: Extreme
The DC-1000CNC Hercules™ high production, horizontal CNC band saws from DoALL are highly efficient, automatic, hydraulically controlled machines with multiple material feeds. Designed for vertical cuts, the DC-1000CNC is ideal for serial production in industrial settings. Thanks to the robust construction of the DC-1000CNC, it is possible to cut a wide range of full and profile materials including stainless and tool steel. In addition, the "box" or enclosed design provides very safe operation. A large variety of optional accessories are available to customize the machine for specific sawing requirements.
- Cutting Capacity Round (Tube or Solid): 33.45" (850mm)
- Cutting Capacity Rectangle: 33.45 x 39.37" (1000x850mm)
- Maximum Bundle Capacity: 39.37 x 24" (1000x610mm)
- Band Saw Blade Width: 2.64 x 0.063" (67x1.6mm)
- Maximum Blade Length: 373.6" (9490mm)
- Band Speed: 50-262 fpm (15-80mpm)
- Band Drive: 15 hp (11.1kW)
- Hydraulic Pump: 5.4 hp (4kW)
- Coolant Pump: 0.2 hp (0.155kW)
- Material Pass Line Height: 24.4" (620mm)
- Machine Weight: 30204 lbs (13700kg)
- Dimensions W x L x H: 246 x 161 x 128" (6230x4080x3250mm)
- Index Single Stroke Min-Max: 0.12-39.4" (3-1000mm)
- Auto Index Multiple Stroke Max: 394" (9999mm)
Standard Equipment:
- Siemens saw control
- Work light
- Hydraulic band tension
- Work height sensor
- Automatic guide arm setting
- Automatic feed control with programmable feed rates
- Variable vise pressure control - Set of 2
- Power-driven, band brush
- Chain chip conveyor with large pan
- Automatic retraction of material in cycle for protection of carbide blades
- Dual acting index vice jaws for crooked stock
- Retractable stationary machine vice jaw
- Set up tools
- Complimentary DoALL cutting fluids package
- One DoALL bi-metal saw blade
- Instruction and parts manuals on CD
