Marvel Spartan 16" x 28" Vertical Plate Saw, Model PS 1628/10/15/20 - NEW

SKU # 2322001

SPARTAN MODEL PS-1628/10 VERTICAL MOVING HEAD PLATE SAW WITH 2 INCH BLADE

Capacity:  16" (400 mm) Height x 28" (700 mm) Width x 118" (3 meters) Length

Blade:  2" (54 mm) x .063" (1.6 mm) x 20'-4" (6200 mm)

Support Table Width:  Inner Table        27.5" (700 mm)
Outer Table       63" (1600 mm)

Speed Range:  65-325 fpm (20-100 m/min.) infinitely variable, driven by heavy-duty worm gear transmission and variable  speed pulley.

Feed Rate:  .080-20"/m (2-500 mm/min.)

Motors:            Blade Drive                   7.5 H.P.
Feed Drive                       1 H.P.
Hydraulic Pump                2 H.P.
Coolant Pump                   1 H.P.

Automatic Chip Removal:  The chip auger rotating in the coolant return removes chips quickly and efficiently, freeing the operator to perform more productive operations.

Table Height:  53.125" (1350 mm)

Overall Dimensions:  31' 2" (9500 mm) Long x 8'10" (2700 mm) Wide, with 6 meter table.

Machine Height:  10' 2" (3100 mm)

Machine Weight:  Approximately 22,000 lbs. (10,000 kg) (20' model)

STANDARD FEATURES

• Space Saving Moveable Saw Head


• Precision Linear Ways


• Hydraulically Positioned Saw Guide Arm


• Hydraulic Blade Tension


• AC Servo Feed


• Programmable Feed and Blade Speed Settings


• Rapid Approach and Return of Saw Head


• Motion Detector


• Automatic Feed Adjustment


• On-Screen Self Diagnostics


• Out-of-Square Detector


• Powered Chip Brush

Priced with an 118" Table, Available with 177" or 236" Table
