Chicago Box and Pan Hand Brake
Chicago Box and Pan Hand Brake, Model BPU - NEW
SKU #4502000
12 GA Hand Brake
Hand Brake incorporates all of the outstanding features of the standard hand brake plus removable, sectioned fingers that can bend any length of metal from 3 inches to the full length of the machine.
ACCESSORIES
- Back Gauge: 25 1/2 inch travel
- Extension Fingers
- Open End Fingers
- Fingers to meet specific requirements
- Radius Nose Bars
- Insert Bar - 1/4 inch
| Model Number | Bending Length | Capacity Mild Steel | Capacity Stainless Steel | Shipping Weight | Dimensions-L | Dimensions - W | Dimensions- H | |
|---|---|---|---|---|---|---|---|---|
| BPU 412-6 | 48" | 12 GA. | 16 GA. | 2065 | 90" | 53" | 60" | |
| BPU 612-6 | 72" | 12 GA. | 16 GA. | 2670 | 117" | 53" | 60" | |
| BPU 812-6 | 96" | 12 GA. | 16 GA. | 3750 | 141" | 56" | 65" | |
| BPU 1014-6 | 120" | 14 GA. | 18 GA. | 4350 | 165" | 56" | 65" |
REF: 013187
Similar Machines
Browse All Equipment Listings
Used
Chicago
VZMS HQ (Alto)
Chicago 6' x 12 Gauge Box and Pan Hand Brake, Model BPU 612-6 – NEW
Asset #: 17017I
Call for Price
New
Tennsmith
Tennsmith 6' x 16 GA Box & Pan Brake, Model HBU72-16 - NEW
